جهاز ال  اف كار اف 7 اس جي هو جهاز شامل يفحص السيارات الصغيرو و السيارات الشحن الثقيل ك الشاحنات و الباصات و عدد الحفر او ما يسمى بالحفارات و مكائن الديزيل و المعدات لزراعيه فهو جهاز شامل لكل السيارات 12 فولت و 24 فولت و بجميع انواعها اسيويه صينيه و كوريه و يابانيه و اوروبيه و امريكيه حتى الهنديه و الماليزيه و الاستراليه و بتحديث سنتان تتمدد احياننا ل 3 سنوات حسب العروض المتاحه من الشركه الصانعه كما و يدعم عدة لغات منها الغه العربيه و لاكن ليس بشكل كال لا بل بنسبه معقوله و ما يميز هذا الجهاز ان فيه معلومات عن اكثر من 200 نوع من المركبات عن كيفية تتبع الاخطاء و الصيانه و يدعم هذا الجهاز خاصية الشبك التلقائي و التعرف على السيارات

يقوم هذا الجهاز بفحص اعطال السيارات و كشفها و مسح الاعطال و الوضائف الخاصه جميعها كضبط دواسة البترول و ضبط الستيرنج الكهربائي و الكرانك شافت و برمجة القير  دبة البيئه و غيار الزيت و دواسة البترول و ضغط العجلات و ضبط الانوار و الابواب و الايرباقات و و و و

لطلب الجهاز اتصلو على 00971501679410

• Hardware

• 1. Extraordinarily powerful Cortex-A9 quad-core processor
• 2. 9.7” 1024x768 LED-backlit glossy Multi Touch capacitive display with IPS technology
• 3. Internal reliable and fast 32GB Solid State Drive for better performance
• 4. Built-in 5-megapixel rear camera with autofocus and flashlight
• 5. Dual-band (2.4 GHz & 5.0 GHz) 802.11n Wi-Fi to access your favorite web resources
• 6. Unique shop tough ergonomic design features strong rubber protection and housing;
• 7. Built-in rechargeable lithium-ion battery for up to 8 hours of continuous operation
• 8. USB, audio and auxiliary ports make it easy to connect accessories
• 9. The VCI connects to the main unit wirelessly with up to 230 meters working range

• Software

• 1. Open source Android Operating System for fast boot-up and multitasking
• 2. Easy and intuitive navigation makes finding what you need simple and fast
• 3. Extensive vehicle coverage for more than 80 US, Asian and European commercial vehicle makes and machines
• 4. Complete capabilities for codes, live data, actuation tests, adaptations and ECU coding
• 5. Displays live data in text, graph, analog and digital gauge for easy data review and analysis
• 6. Configures display options, sets triggers, records and playbacks results with one touch
• 7. Records and playbacks live data to pinpoint troubles of sensors and components
• 8. Cloud-based Data Manager saves customer and vehicle records, scanner data and technician notes
• 9. Remote technical support for convenient demonstration, training and increased customer satisfaction
• 10. Prints out recorded data anytime and anywhere with Wi-Fi technology
• 11. Automatic Wi-Fi updates available in new software releases

احدث جهاز من شركة اكستوول لفحص المعدات الثقيله بشاشه 10 انش و وصلة الشاحنات و كوابلها حيث يفحص الشاحنات بكل انواعها و مكائن الديزيل و معدات

البناء مثل      الجرافات و الكرينات و المولدات الكهربائيه و يفحص السيارات الكهربائيه

ارجو مشاهدة الفيديو بالاسفل

• OEM-Level Software
• Full Vehicles Coverage
• Compatible with DOIP Protocol
• Compatible with SAE J2434-1 and J2534-2
• Special Functions
• Full Vehicles Coverage
• Full System Diagnosis
• Live data stream

Basic Functions

• MCM Engine Management e.g Read fault codes, clear fault codes, Service Routines, Read Data Streams
• Active tests;
  • Target Engine speed r/min
  • Exhaust brake solenoid valve
  • Engine stop forced drive
  • EGR position
  • Fuel leak Check
  • VNT Position %

Special Functions

• Mechanical compression ration detection
• Dynamic contrast measuring cylinder
• Flow detection idle running amendments
• Frequency Counter
• Fuel Consumption
• Injector Coding
• DPF Regeneration
• ERG leaning

VCI Diagnostic Box

• Display voltage, Bluetooth connection status, etc.
• Work together with the extension cable and various types of connectors to communicate with vehicle diagnostic port
• work together with DB9 male to USB3.0 cable to communicate with the tablet.

Accessories

• Certificate of quality
• Carton Box
• User Manual
• Micro USB Cable
• Charger for Tablet

 اقوىاجهزة الفحص و البرمجة الشامل لجميع انواع السيارات جهازجيسكان 3 للسيارات الصغيره 12 فولت و الكبيرة 24 فولت

G-scan3 الجهاز الاصلي الوحيد في الاسواق كما انه جهاز الوكالات المعتمد للكيا و الهونداي

 G-scan3 كما اثبت جهاز جي سكان جدارته في قوة الفحص على السيارات الامريكية و الاوربي والياباني

  هو الجيل الثالث من اجهزة جيسكان العريقه حيث انه المطور من جيسكان 2

حيث ان شركة الجيسكان طورت الاصدارات القديمه من حيث الهاردوير والسرعه و النظام و الامكانيات و ان الجهازيبرمج اون لاين هيونداي و كيا

و ميزة الجيسكان عن باقي الاججهزة انه يمكن ان يعمل ك باس ثرو بمعنى انه اذا امتلكت اشتراك فورد او جي مثلا فيمكن ان يقوم الجي سكان مكان الوصله ولا داعي لشراء وصلة متخصصه لكل نوع من السيارات و بذالك تستطيع توفير مبالغ كبيرة جدا

تعمل شركة جيسكان حثيثا مع مرسيدس و بي ام لاطلاق برمجة اون لاين مجانييخلال الاشهر القادمه - انتضرو المفاجئه

باختصار يدعم جهاز الجيسكان وسائل الاتصال الوكيله

OEM supported vehicle communication protocol( نظام وكالات )

بعض ميزات جهاز G-scan3 :

1- جهاز فحص و برمجة شامل لجميع انواع السيارات اختصاصي في الكيا و الهونداي و قوي جدا على السيارت الامريكي و الاوربي و اليابانية و الكورية (القديم منها و الحديث )

- يفحص السيارات الكهربائية و الهايبرد و البنزين و الديزل (12-24 فولت)

- يفحص جميع كمبيوترات السيارة و حساساتها

- المحرك – جير –شصي – بودي

- System search

TCCs (Engine/AT)

 Transmission (ECT-SMT)

- Hybrid Vehicle

- Mild hybrid vehicle

- Hybrid vehicle Battery

- ABS/VSC/ARS

- Air suspension/TEMS/AHC

- Stabilizer

- Electric parking brake

- ARS(Active rear steer)

- SRS Airbag

- 4WD(4 wheel drive)

- EPS

- Radar cruis control

- Stop and Go

- VGRS (variable Gear ratio Steering)

- Immobiliser

- Precrash safety System

- IPA (Intelingent Parking Asist)

- Combination meter

- Air conditioner

- EMS (energy Management system)

- Motor Generator

- Milliwave radar

- LKA(lane keeping Assist)

- Active Stabilizer (rear)

- Body muti-system

جميع ما ذكر لديه امكانية DTC Analysis قراءة جميع الاعطال

DATA analysis قراءة البيانات الحية بما يسمى اللايف داتا

Actuation testلفحص الانظمة الكهربائيةSpecial function لبرمجة الانظمة التي تحتاج معايرة( لعمل اختبارات المشغلات المختلفة –عمل اختبار التسريب EVAP-EGT – عمل restting لكنترول الجير –تغريغ دائرة الفرامل ABSمن الهواء – برمجة بخاخات الديزل لكنترول المحرك – ضبط الاجزاء الالكترونية و برمجتها –ضبط اضاءة الزيوت لسيارة التي تحتاج لضبط الكتروني – امكانية تكويد المفاتيح المشفرة في حال توفر pin code و برمجة الريموت في حال عدم عمله

برمجة ستيرنج انجل-ABS LEANER- كبك الدعسة IDLE air control(throttle)- عمل learning coding ECU و البرمجيات المتعددة و المزيد المزيد من الميزات التي لم تذكر

•

  Higher Performance CPU

  Equipped with a powerful Samsung’s Exynos 7420 Octa-core processor for an ideal management of workshop operations to keep all vehicle records, customer information, and other necessary images and data.

•

  Smarter and Faster Operating System

  Based on the Android 6.0 system provides improved user interface and experience for fast boot-up, multi-tasking, better networking and enhanced system security.

•

  Capacitive Touch Screen on 10.1” LCD

  User Interface through a capacitive touch screen technology provides the easiest and the most intuitive use of the diagnostic scan tools and its multiple functions. High resolution TFT screen offers greater readability and convenient touch-screen operation.

•

  Extensive Storage Capability

  The internal flash of 64GB accommodates software applications and data for all brands with room to spare, and the external memory space up to 128GB allows an extensive storage for saving images and recorded data.

•

  Powerful Oscilloscope

  Measures the voltage or amperage signals of the vehicle’s sensors and actuator circuits to display these signals on the high resolution 4 trace scope.

•

  Pre & Post Diagnostic Report

  Designed to easily create a diagnostic report. The pre-scan report will highlight any issues that vehicles have, while the post-scan report will confirm that they have been resolved properly.

•

  24V Commercial Vehicles

  Designed to support the 24V commercial vehicles systems, make direct connection to the buses and trucks. (Not available for US and Canada)

•

  Wireless Connectivity

  Wi-Fi connection to the Internet allows for smart updates, quick feedback, TeamViewer support, wireless printing option, browsing and many more.

•

  J2534 Pass-thru

  Serves as a “Pass-thru” device for programming the ECUs on both Hyundai and Kia vehicles ( No domestic Korean vehicles, Only for U.S and Europe )

•

  Rechargeable Battery

  Equipped with a rechargeable 6300 Ah battery. Besides the possibility to use the G-scan without an external power supply for hours, it also enables the advanced diagnostic functions that need to crank the engine.

  Specification

  Category	Specifications
  CPU	Exynos 7420 Octa Core @ 2.1 GHz
  Operating System	Android 6.0
  System Memory	Internal Flash 64GB, RAM 3GB
  External Memory	Micro SD Card (max. 128GB)
  LCD	10.1" TFT (1280 x 800 pixel)
  Input Devices	Capacitive Touch Screen, 3 Hard Keys (Power, Function 1, Function 2)
  Camera	Rear 13MP, AF, Flash Light
  Sound	Speaker(mono), Microphone and Earphone Jack
  Rechargable Battery	Li-ion Polymer, 6300mAh (3.7V), Hard Pack
  Operating Voltage	DC 9 ~ 30V
  Sensors	Gyro-sensor, Acceleration sensor
  Dimension	304 x 208 x 35.5mm
  External Port	USB 2.0 Host 1ea, Host & Slave 1ea
  Video Out	HDMI
  Network	RJ45 Ethernet, WiFi 802.11 a/b/g/n, Bluetooth 4.0

  AC/DC Adapter

  Category	Specifications
  Input Power	100 ~ 240V AC
  Frequency	50 / 60 Hz
  Input Current	0.8 A
  Output Voltage	12V DC
  Output Current	3 A

  • • Diagnostic Report Function

      Allows the users to create a report with Pre-scan and Post-scan result. Not only the users can save the reports as PDF file in G-scan 3’s memory; also with a help of Bluetooth and Wi-Fi technology, users can simply print directly or send them to desired E-mail address.

      •

    • J2534 Pass-thru

      Supports ECU reprogramming on both Hyundai and Kia vehicles in J2534 pass-thru mode. It also operates as a J2534 pass-thru terminal for other vehicle manufactures supporting J2534 programming and diagnostics. This requires OEM-specific diagnostic software and the mode can be used by CAN-Bus, KWP2000, and ISO9141 protocols. ( exceptions may apply )

      •

  • • Simple Menu Structure

      No hassles for locating the metal tag and finding the correct engine codes. Simply select the diagnostic connector type before selecting the system to test when testing Japanese vehicles. No model Code, No Engine Code, No detailed menu selections are required.

      •

    • System Auto Search

      No time consuming DTC search by “trial and error”, G-scan provides auto search function that tries to communicate with “ALL” systems in the car automatically. It reports back with the available system list and the number of DTCs’ of each system. ( Note : Not all vehicle selection menus provide the system and auto search )

      •

  • • Full Text Description

      Thanks to screen control flesibility of Android system and its 1280 pixels wide screen, the full description of DTC codes and data parameter names are supported with G-scan. If longer than the screen, the full description appears in a pop-up window.

      •

    • Flight Record & Graphical Display

      Diagnostic data can be recorded on the road test while the car is running the real driving condition. And recorded data (Flight Record) can be replayed both on G-scan or the larger PC screen. Also, these data can be displayed in graphical waveforms.

      •

  • • Handwritten Memo & Instant Screen Capture

      Press the “View Finder” button on the bottom right corner, the current screen play is captured immediately and you can put your own handwritten memos and drawings by using the fingers or stylus pen. The captured image and the memo are saved in the memory for your retrieval. You can either send the image data to a printer to print or transfer to the PC or phone via bluetooth pairing connection.

      •

  • • Self-Test Function

      Many of field failures are found caused by the defective cable and connector, or the problems on the vehicle side. It gives huge impact on sales by causing complaints of the customers and negative influences by the unsatisfied users. G-scan provides “self-test function” that helps the users to determine whether the communication problem is caused by the base unit’s internal hardware / software reasons or by the external factors. It helps you to keep focused on sales, not on taking care of grumbling customers.

      •

  • Hyundai and KIA OEM S/W

    Complete OEM software package is included (except ECU reprogramming), Select Hyundai or Kia from the Menu. Users can enjoy the complete function and performance of OEM tool for Korea’s leading brands.

    •

  • Data log and quick feedback support

    In cases of communication or function failure, users can log the bi-directional data transmission between the tool and vehicle control systems. This log can be sent to the engineers through the log transfer function within the G-scan 3 device. The given data log files will be analyzed, feedback and patch file update may provided within 24 hours during workdays; when necessary.

    •
